Dow Artificial Soccer Turf Specifications | ||
1 | Grass fiber material features | DuPont Dow artificial grass yarn is made of special polyethylene (PE), food grade environmental protection raw material, heat resistance, cold resistance, UV resistance, acid and alkali resistance, organic resistance, high wear resistance, high tear resistance. |
2 | Colors | Straight grass with fruit green and grass green double color matching and the yellow grass or white grass can be selected for marking, boundary width is 12cm(±0.5cm) |
3 | Dtex | ≥12000D/4F ±5% |
4 | Turf tufting density | ≥10500 s/m2 ±10% |
5 | Height | 50mm±1mm ±10% |
6 | Grass Shape | S type, high wear- resistance, stable structure |
7 | Grass Width | 1.5-2mm |
8 | Grass Thickness | 290μm-320μm |
9 | Bottom needle pattern | lined pattern |
10 | Line Spacing | 5/8 inch |
11 | Waven Spacing | 17 /s/10cm ±0.5s |
12 | Adhensive | Environment-friendly butadiene latex |
13 | Fabric | Three layers of base cloth (composite base cloth + mesh) |
14 | water permeability | Not less than 60L/min/square (before silica sand filling) |
15 | flame resistance | The maximum distance from the center to the damaged edge should not be greater than 50 mm. |
16 | Friction coefficient | 0.6-1.0 |
17 | quality guarantee | The surface of artificial grass is basically flat, without obvious uneven;Uniform density, no obvious needle leakage condition;No obvious color difference;There was no obvious glue spot on grass silk surface.Base cloth coated evenly, there should be no damage phenomenon;Vertical and transverse spacing is uniform, no obvious crooked line jumper.The gum is uniform, the amount of backlight, the bottom of the back after folding no cracking phenomenon, the single cluster pulling force reaches more than 50N. |
18 | The whole course have no color difference, full of elasticity, can be used all day long, the filling material is uniform and flat, the grass fiber does not fade in 8 years, and the strength reduction is not more than 10%.The course as a whole provides more than 8 years of quality guarantee. | |
19 | Impact absorption /(%) | 45-70 |
20 | Vertical deformation /(mm) | 4-11 |
21 | Tensile force/(N) - single grass | ≥15 |
22 | Single tuft single grass pull-out force/(N) | ≥50 |
23 | Anti-aging property of dark green and light green grass silk | 5000H gray card grade ≥4 |
The fracture strength loss is less than 20% | ||
24 | Anti-aging property of yellow streaked grass yarn | 5000H gray card grade ≥3 |
The fracture strength loss is less than 5% |
We has the largest automatic production and research base of sports surface materials in China at present. We strictly control every sector from raw materials to installation. As a"one-stop supplier for sports field material, engineering and service"integrating R&D, production, sales, design, installation and after-sales service, Senria sports continuously introduces advanced production equipment and advanced eco-friendly material production technology at home and abroad, and employs experts and professors in polymer and new material fields from well-known domestic research institutions as technical consultants of Senria new material R& D center, with automatic CNC production line, Senria products are qualified by the national standards of China and IAAF, providing clients with professional products.
Are you manufacturer or trader?
We are professional manufacturer with more than 25 years development and production history , with the 46000 square production and research base in Hunan Province which is the largest automatic sports surface material production base in China at present,ensuring the excellent products quality and timely delivery.
How about your delivery time?
15-25 working days for mass production.
What is the life Span for Running track?
The life span is about 10-15 years.
Is it the EPDM granules made of new EPDM rubber or Recycled rubber?
All of our EPDM granules are made of environment-friendly New EPDM rubber, not recycled rubber.
What is the products guarantee time?
5 years product warranty.
What is your terms of delivery?
EXW, FOB, CFR, CIF...
How is your sample charge?
Free of charge with small quantity , Express delivery time would be 4-7 days.
